White CoexFlex™ 60A TPU

White CoexFlex™ 60A TPU

***60A is very soft and can be challenging to print with. A direct drive extruder with a contained filament path (it will squeeze out any gap it can) and a PTFE-lined hot end (it tends to stick to the walls of an all-metal hot end) is recommended. Seasoning an all-metal hot-end may help.***

CoexFlex™ 60A TPU is, by far, the most flexible filament on the market. At Shore 60A, it is much softer than Ninjaflex or Filaflex, feels like a rubber band, and produces finished parts that are completely flexible no matter what infill density you use. Highly functional for applications that require stretch, flexibility, or compliance. (NOTE: Only printable with select printers capable of printing this durometer of filament. A direct drive extruder is required.  If you are unsure if your printer can print this material, please contact us prior to purchase!)

Benefits of CoexFlex™ 60A TPU

• Excellent layer adhesion
• Incredible flexibility and elasticity
• Great durability

Uses

• Soft handles and grips
• Protective cases and skins
• Custom-shaped seals and gaskets
• Soft and flexible functional parts

Recommended print settings

• Hotend Temperature: 205°C – 215°C (DO NOT approach or exceed the material breakdown temperature of 230°C)
• Bed Temperature: Bed heating not recommended.
• Recommended build surfaces/adhesives:
• BuildTak
• PEI
• Kapton Tape
• Hairspray
• Magigoo Flex
• Magigoo
• Painter’s Tape
• Print speed – up to 40mm/s. Start very slow (20mm/s) and work up from there. Slow down for bridging and infill.
• Extrusion multiplier – up to 1.25 compared to rigid material, depending on extruder tension
• Extrusion width – 105% of nozzle diameter (0.42 for a 0.4mm nozzle)
• Part cooling fan recommended
